Grade： No signal contact,Non-polar capacitor / Polarization signal contact

Mechanics:

Work intensity:3,5N<PUSH< 45N / 5N<PULL< 30N

Endurance: No load: 5000second

Resistive load: 2500Next time

Tightening torque: bucket nut: recommend: 4 ± 0.25 N.mmaximum : 5.0 N.mTerminal screws: recommend: 1.6 ± 0.1 N.mmaximum : 2.0 N.m

environment

Salt spray:48h 5% NaCl

humidity： test b RTCA DO160 10Next time

Working temperature:-60°C +125°CApplicable to all levels except 30 A: - 60°C + 90°C

accelerate (centrifugal) ：17 g
